ART 310 MKIII

PASSIVE TWO-WAY SPEAKER
  • 300 Watt power handling
  • 127 dB max spl
  • 90 x 70, Wide dispersion constant directivity horn
  • 10" woofer, high power 2,5" voice coil
Support
Features Specifications Downloads
Support
Features
  • 300 Watt power handling
  • 127 dB max spl
  • 90 x 70, Wide dispersion constant directivity horn
  • 10" woofer, high power 2,5" voice coil
  • 1" HF neo driver, Mylar dome 1.5" voice coil

ART 310 is a 10” passive speaker ideal for installation purposes. Thanks to its high quality neodymium transducers and very compact sized cabinet, it is the perfect speaker in all the situations where the output of a PA system and the size of a monitor are important. The 10” woofer features a 2.5” voice coil and delivers very high efficiency and controlled bass reproduction. The ART 310 is very easy to install due to it being incredibly lightweight and the two M10 fly points

ARCHIVED

Part number:

13000374
ART 310 MKIII
EAN 8024530009878

Responsive Image

PRECISION ACOUSTIC DESIGN

RDShape is an advanced simulation software, purpose-built for acoustic modeling and system optimization of RCF speaker and subwoofer systems. Designed to streamline the design, setup, and tuning process, RDShape is a versatile tool for touring professionals, venue designers, and sound engineers. Whether planning a small performance or a large-scale installation, RDShape ensures precise predictions, seamless configuration, and robust safety compliance.

XPS 16 Configurations Examples

FULL RANGE TWO-WAY LINE ARRAY WITH SUBS
12 x Double 6" Line Array and 6 x Single 15" Sub
Small to Medium Size Venues, Worship Spaces, Sports Facilities, and Concert Halls
Responsive Image
FULL RANGE TWO-WAY LINE ARRAY WITH SUBS
12 x Double 6" Line Array and 6 x Single 15" Sub
Small to Medium Size Venues, Worship Spaces, Sports Facilities, and Concert Halls
Responsive Image
FULL RANGE TWO-WAY LINE ARRAY WITH SUBS
12 x Double 6" Line Array and 6 x Single 15" Sub
Small to Medium Size Venues, Worship Spaces, Sports Facilities, and Concert Halls
Responsive Image
FULL RANGE TWO-WAY LINE ARRAY WITH SUBS
12 x Double 6" Line Array and 6 x Single 15" Sub
Small to Medium Size Venues, Worship Spaces, Sports Facilities, and Concert Halls
Responsive Image
Die Show kann beginnen
Höhenverlängerungen, Schutz- und Transportzubehör
Test Title
Test Subtitle
Responsive Image

ADVANCED CROSSOVER ENGINE

FACTORY-TUNED PRESETS FOR PERFECT SUB-TOP PAIRING
Pair your full-range speaker with RCF ACE-enabled SUBs and unlock your system's true potential.
RCF’s proprietary Advanced Crossover Engine (ACE) is engineered to precisely match the time delay and align the phase on a broader range than the usual crossover frequency range between RCF subwoofers and FiRPHASE-enabled full-range speakers.
Specifications
Acoustical specifications
Frequency Response (-10dB)
50 Hz - 20000 Hz
Max SPL @ 1m
127 dB
Horizontal coverage angle
90°
Vertical coverage angle
70°
Power section
Crossover Frequencies
1800 Hz
Transducers
Compression Driver
1 x 1.0'' neo, 1.5'' v.c
Woofer
1 x 10'', 2.0'' v.c
Input/Output section
Input connectors
Speakon
Output connectors
Speakon
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
PP Composite
Hardware
2 x M10 Flying p.
Handles
1 Top
Pole mount/Cap
35 mm insert
Color
Black
Size / Weight
Height
537 mm / 21.14 inches
Width
337 mm / 13.27 inches
Depth
314 mm / 12.36 inches
Weight
13 kg / 28.66 lbs
Shipping information
Package Height
600 mm / 23.62 inches
Package Width
396 mm / 15.59 inches
Package Depth
372 mm / 14.65 inches
Package Weight
15 kg / 33.07 lbs
