ARCHIVED
LIVE SOUND

ART 732-A

ACTIVE TWO-WAY SPEAKER
  • 1400 W Peak, 700 Watt RMS digital amplifier
  • 12" woofer, high power 2.5" voice coil
  • 1.4" HF neodymium driver, titanium dome, 3.0" voice coil
  • 131 dB max spl
Support
Features Specifications Accessories Downloads
Support
Features
  • 1400 W Peak, 700 Watt RMS digital amplifier
  • 131 dB max spl
  • 90 x 60, Wide dispersion constant directivity horn
  • 12" woofer, high power 2.5" voice coil
  • 1.4" HF neodymium driver, titanium dome, 3.0" voice coil
  • PFC power factor correction
  • DSP Processing

The ART 732-A is a unique product in its category. The titanium dome, 3.0” voice coil, neo compression driver offers a unique vocal clarity and sound projection. The 12” woofer guarantees a linear response and a precise, deep low frequency control. The transducers are built using the most advanced assembly technologies. The amplifier delivers 1400 Watt and is controlled by a DSP that takes care of crossover, equalization, phase alignment, soft limiting and speaker protections.

ARCHIVED

Part number:

13000467
ART 732-A
220-240V, EAN 8024530013035

13000468
ART 732-A
115V, EAN 8024530013042

Specifications
Acoustical specifications
Frequency Response
50 Hz ÷ 20000 Hz
Max SPL @ 1m
131 dB
Horizontal coverage angle
90°
Vertical coverage angle
60°
Transducers
Compression Driver
1.4'', 3.0'' v.c
Woofer
12'', 2.5'' v.c
Input/Output section
Input signal
bal/unbal
Input connectors
XRL, Jack
Output connectors
XRL, Jack
Input sensitivity
-2 dBu/+4 dBu
Processor section
Crossover Frequencies
900 Hz
Protections
Thermal, RMS
Limiter
Soft Limiter
Controls
Volume, EQ Shape
Power section
Total Power
1400 W Peak, 700 W RMS
High frequencies
400 W Peak, 200 W RMS
Low frequencies
1000 W Peak, 500 W RMS
Cooling
Convection/Forced
Connections
VDE
Standard compliance
Safety agency
CE compliant
Physical specifications
Hardware
2 x M10 Flying p.
Handles
2 side, 1 top
Color
Black
Size / Weight
Height
637 mm / 25.08 inches
Width
384 mm / 15.12 inches
Depth
363 mm / 14.29 inches
Shipping information
Package Height
680 mm / 26.77 inches
Package Width
440 mm / 17.32 inches
Package Depth
420 mm / 16.54 inches
Package Weight
20.4 kg / 44.97 lbs
Accessories
Downloads
MANUALS
USER MANUAL - ENG ITA
PDF
204 KB
22-05-2024
SPECIFICATIONS
SPECSHEET - ENG
PDF
993 KB
18-10-2024
SPECSHEET - FRA
PDF
997 KB
18-10-2024
SPECSHEET - SPA
PDF
995 KB
18-10-2024
