CS 6940EN
TWO-WAY COLUMN SPEAKER
- 8 x 3" fullrange transducers with 0.75" dome tweeter.
- Power selectable (100 V): 40 W – 20 W – 10 W – 5 W – 2.5 W.
- 95 dB sensitivity.
- Colour white RAL 9003.
EN 54
WEATHERPROOF






















Features
- 8 x 3" fullrange transducers with 0.75" dome tweeter.
- Power selectable (100 V): 40 W – 20 W – 10 W – 5 W – 2.5 W.
- 95 dB sensitivity.
- Colour white RAL 9003.
- Aluminium body, grille and bracket.
- In/out ceramic terminal block.
- Thermal fuse protection.
- Protection grade IP66.
CS 6940EN is a compact and elegant two-way column speaker providing highly intelligible voice reproduction, and suitable for installation into places of worship, stations, subways and many other environments. The terminal connection blocks, for input and output flameproof cables, are made of ceramic material. A thermal fuse protects the integrity of the line in case of heat affecting the speaker. Ground screw available (if needed). Thanks to its IP66 protection grade, it can be installed both indoor and outdoor.
Part number:
13100005
CS 6940EN
EAN 8024530013684
Specifications
Acoustical specifications
Frequency Response (-10dB):
140 Hz ÷ 20000 Hz
Max SPL @ 1m:
109 dB
Max SPL @ 4m:
97 dB
Horizontal coverage angle:
194°
Vertical coverage angle:
30°
System Sensitivity:
95 dB
System Sensitivity 1W @ 4m:
83 dB
Power section
Power Handling:
40 W
Peak Power Handling:
160 W PEAK
Recommended Amplifier:
80 W
Protections:
Thermal fuse
Transducers
Dome Tweeter:
0.75''
Fullrange:
8 x 3.0''
Input/Output section
Input connectors:
Ceramic screw terminals
Output connectors:
Ceramic screw terminals
Constant Voltage Transformer:
70/100 V
Power selection 1:
40 W - 250 ohm
Power selection 2:
20 W - 500 ohm
Power selection 3:
10 W - 1000 ohm
Power selection 4:
5 W - 2000 ohm
Power selection 5:
2.5 W - 4000 ohm
Standard compliance
IP protection grade:
IP 66
Safety agency:
CE compliant
EN54-24 certified:
Yes
CPR number:
1488-CPR-0490/W
Physical specifications
Cabinet/Case Material:
Aluminium
Grille:
Aluminium
Color:
White - RAL 9003
Size
Height:
995 mm / 39.17 inches
Width:
114 mm / 4.49 inches
Depth:
96 mm / 3.78 inches
Weight:
7 kg / 15.43 lbs
Shipping information
Package Height:
200 mm / 7.87 inches
Package Width:
1090 mm / 42.91 inches
Package Depth:
170 mm / 6.69 inches
Package Weight:
8.4 kg / 18.52 lbs
Downloads
RCF products are continually improved. All specifications are therefore subject to change without notice.
