VOICE ALARM EN54

DP 4EN

UNIDIRECTIONAL SOUND PROJECTOR

4" fullrange transducer.
Power selectable (100 V): 10 W – 5 W – 2.5 W.
91 dB sensitivity.
Colour grey RAL 7035.

EN 54

IP55

Where to buy

Features

4" fullrange transducer.
Power selectable (100 V): 10 W – 5 W – 2.5 W.
91 dB sensitivity.
Colour grey RAL 7035.
Flameproof ABS body, aluminium grille and bracket.
In/out ceramic terminal block.
Thermal fuse protection.
Protection grade IP55.

DP 4EN is a unidirectional sound projector featuring an elegant aesthetic and easy orientation, suitable for the sonorization of commercial and industrial environments where a good sound quality and high intelligibility and efficiency are required. It features a cylindrical plastic body with aluminium grille and U-bracket support. Thanks to its IP55 protection grade, it can be installed both indoor and outdoor.

Part number:

13100021
DP 4EN
EAN 8024530014766

Specifications

Acoustical specifications

Frequency Response (-10dB)

180 Hz ÷ 16000 Hz

Max SPL @ 1m

101 dB

Max SPL @ 4m

89 dB

Coverage angle

180°

System Sensitivity

91 dB

System Sensitivity 1W @ 4m

79 dB

Power section

Power Handling

10 W

Peak Power Handling

40 W PEAK

Protections

Thermal fuse

Recommended Amplifiers

DXT 3000, DXT 4000, DXT 7000

Transducers

Fullrange

1 x 4.0''

Input/Output section

Input connectors

Ceramic screw terminals

Output connectors

Ceramic screw terminals

Constant Voltage Transformer

100 V

Power selection 1

10 W - 1000 ohm

Power selection 2

5 W - 2000 ohm

Power selection 3

2.5 W - 4000 ohm

Standard compliance

IP protection grade

IP 55

Safety agency

CE compliant

EN54-24 certified

Yes

CPR number

0068-CPR-085/2017

Physical specifications

Cabinet/Case Material

ABS

Grille

Aluminium

Color

Grey - RAL 7035

Size / Weight

Depth

200 mm / 7.87 inches

Diameter

137 mm / 5.39 inches

Weight

1.7 kg / 3.75 lbs

Shipping information

Package Height

290 mm / 11.42 inches

Package Width

190 mm / 7.48 inches

Package Depth

160 mm / 6.3 inches

Package Weight

2.1 kg / 4.63 lbs
