ARCHIVED
MIXING CONSOLES

L-PAD 12CX

12 CHANNEL MIXING CONSOLE WITH EFFECTS
  • 6 mono INPUT + 4 stereo INPUT
  • 4 Compressors (Ch. 1-4)
  • Internal Digital Effects: 99 preset
  • Internal PSU 100V-240V, 50-60Hz, 40W
Support
Features
  • 6 mono INPUT + 4 stereo INPUT
  • 4 Compressors (Ch. 1-4)
  • 3band/2band EQ
  • 1 AUX send
  • 1 FX send
  • Internal Digital Effects: 99 preset
  • Internal PSU 100V-240V, 50-60Hz, 40W

With six transparent sound mic inputs, four stereo line inputs and the 2tk in/out L-PAD12CX is the ideal tool for small band gigs, complex conference, corporate events and all situations where it is necessary to handle several signals. Four single-control compressors on mic channels help to handle even the more dynamic-complex signals. The 99 preset Internal FX DSP allows the sound to be enhanced by adding accurate and warm effects. When not in use for Internal effects the FX send and the AUX sends allow small stage control, with the appropriate wedge monitors. The super versatile L-PAD slot permits the optional L-PAD MP3 PLAYER, PLAYER/RECORDER or BLUETOOTH CONNECTION cards to be inserted.

ARCHIVED

Part number:

17140034
L-PAD 12CX
90-240V, EU, EAN 8024530011215

17140041
L-PAD 12CX
90-240V, US, EAN 8024530011222

17140044
L-PAD 12CX
100V, JP, EAN 8024530011413

17140045
L-PAD 12CX
240V, AU, EAN 8024530011420

17140062
L-PAD 12CX
240V, UK, EAN 8024530011598

Specifications
Electronic specifications
Frequency Response:
20 Hz ÷ 22000 kHz
Inputs
Mic:
6
Gain Range:
0 dB ÷ 50 dB
Mic Inputs Impedance:
2 kohm
Low Cut:
75 Hz
Phantom Power +48V:
Yes
Mono Line:
4
Gain Selection:
15 dB ÷ 35 dB
Line Input Impedance:
10 kohm
Outputs
Main MIX:
1
Control Room:
Yes
FX Send:
1
AUX Send:
1
AUX Output:
2
Phones:
1
2 Track:
Yes
Outputs specifications
Main Out Impedance:
120 ohm
Main Out Level:
22 dBu
Aux Out Impedance (ohm):
120 ohm
Aux Out Level:
16 dBu
Compressors
RCF Compressors:
On Channell 1-4
EQ
Input Channels EQ:
3 Generic
Auxiliary sends
AUX:
1 PRE/POST
FX POST:
1
Internal Effects
Send Effects:
99
Other features
Footswitch:
Yes
Electrical specifications
Power supply:
Internal
Voltage requirements:
100 V - 240 V
Power consumption (MAX):
40 W
Physical specifications
Cabinet/Case Material:
ABS
Size
Height:
93 mm / 3.66 inches
Width:
341 mm / 13.43 inches
Depth:
474 mm / 18.66 inches
Weight:
3.93 kg / 8.66 lbs
Shipping information
Package Height:
160 mm / 6.3 inches
Package Width:
540 mm / 21.26 inches
Package Depth:
440 mm / 17.32 inches
Package Weight:
5.04 kg / 11.11 lbs
