V 221-S PASSIVE BASS REFLEX SUBWOOFER
Search RCF products
Choose search system
ARCHIVED
V 221-S
PASSIVE BASS REFLEX SUBWOOFER
- 4000 Watt AES
- 2 x 21" high power, 4.5" voice coil hypervented woofers
- High power, bass reflex subwoofer system
- 143 dB max SPL
Features
- High power, bass reflex subwoofer system
- 2 x 21" high power, 4.5" voice coil hypervented woofers
- 143 dB max SPL
- 4000 Watt AES
- Very high output, response down to 30 Hz
- Birch plywood cabinet
- Weather resistant, textured, polyurea finish
- Epoxy powder coated front grille
The V221-S is a very high-output bass reflex subwoofer. The system is equipped with two advanced 21” RCF precision woofers mounted in a front-loaded configuration. This new high power design marks the latest refinements in RCF experience in compact subwoofer design, resulting in a fast and controlled reproduction of the bass frequency range. The two transducers couple to achieve tight and maximised output, while the subwoofer design ensures an efficient acoustic response down to 25 Hz.
ARCHIVED
Part number:
13000415
V 221-S
EAN 8024530012649
Specifications
Acoustical specifications
Frequency Response (-10dB)
25 Hz ÷ 200 Hz
Max SPL @ 1m
143 dB
System Sensitivity
100 dB
Power section
Nominal Impedance
4 ohm
Power Handling
4000 W
Peak Power Handling
16000 W PEAK
Transducers
Woofer
2 x 21'', 4.5'' v.c
Input/Output section
Input connectors
Speakon® NL4
Output connectors
Speakon® NL4
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
Baltic birch plywood
Pole mount/Cap
Yes
Grille
Steel
Size / Weight
Height
585 mm / 23.03 inches
Width
1500 mm / 59.06 inches
Depth
870 mm / 34.25 inches
Weight
110 kg / 242.51 lbs
Shipping information
Package Height
600 mm / 23.62 inches
Package Width
1540 mm / 60.63 inches
Package Depth
900 mm / 35.43 inches
Package Weight
110 kg / 242.51 lbs
