Features
  • True active 35 W + 20 W class AB design
  • 50 Hz – 20.000 Hz frequency response
  • Precision directivity tweeter waveguide
  • Fully featured input board
  • 5" composite fiberglass woofer
  • 1" soft dome tweeter
  • Reflection free front cabinet design
  • Low distortion reflex port

AYRA 5 is a two-way reference studio monitor that is designed for near field applications, equally suited to your home recording studio. AYRA 5 features a high quality soft dome tweeter and a 5” composite fibreglass woofer. The AYRA Series is optimized to deliver the best sound for a variety of applications. Whether you are working with a near field mix at your home studio, you need a clear and loud sound for your multimedia gaming or simply need some good monitors for your personal computer.


ARCHIVED

Part number:

13041005
AYRA FIVE
220-240V, Black, EAN 8024530007249

13041006
AYRA FIVE
115V, Black, EAN 8024530007256

13041021
AYRA FIVE W
220-240V, White, EAN 8024530010300

13041022
AYRA FIVE W
115V, White, EAN 8024530010317

13041026
AYRA FIVE
100V, Black, EAN 8024530010638

13041034
AYRA FIVE W
100V, White, EAN 8024530012465

Specifications
Acoustical specifications
Max SPL @ 1m
106 dB
Horizontal coverage angle
110°
Vertical coverage angle
70°
Transducers
Compression Driver
1.0'', 1.0'' v.c
Woofer
5.0''
Input/Output section
Input signal
bal/unbal
Input connectors
XLR, Jack, RCA
Input sensitivity
-2 dBu
Processor section
Crossover Frequencies
2100 Hz
Protections
Thermal, RMS
Limiter
Soft Limiter
Controls
HF Adjust
Power section
Total Power
110 W Peak, 55 W RMS
High frequencies
40 W Peak, 20 W RMS
Low frequencies
70 W Peak, 35 W RMS
Cooling
Convection
Connections
XLR, Jack, RCA
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
MDF
Color
Black, White
Size / Weight
Height
274 mm / 10.79 inches
Width
186 mm / 7.32 inches
Depth
266 mm / 10.47 inches
Weight
6.51 kg / 14.35 lbs
Shipping information
Package Height
385 mm / 15.16 inches
Package Width
345 mm / 13.58 inches
Package Depth
275 mm / 10.83 inches
Package Weight
7.5 kg / 16.53 lbs
